ABS M5 Kit ClubSport

When it comes to motorsport racing, having the right ABS system can make all the difference. The Bosch Motorsport ABS M5 Clubsport Kit is regarded as one of the best racing ABS systems on the market, combining advanced features, adaptability across vehicle types, and significant improvements in braking performance and lap times - making it a top choice for drivers at every level of competition.

The M5 system features updated control algorithms and new hardware over previous generations, delivering improved wheel slip control and stronger brake performance across a wider range of racing conditions. Its intelligent control algorithms continuously monitor vehicle dynamics for maximum deceleration while preventing wheel lock-up, and the system offers roughly a 20% increase in braking capability compared to stock/OEM systems. Because there are no low-grip or ice-condition modes, the M5 is purpose-built for high-performance racing environments rather than street or all-weather use.

Each ABS M5 unit is calibrated to the specific vehicle it's installed on using Bosch's RaceABS configuration software, ensuring the system is tuned to that car's dynamics rather than running a generic map.

Key Features

• Integrated ECU and hydraulic unit in a single housing
• 12-position driver-adjustable function switch for on-the-fly ABS intervention control
• Compatible with FWD, RWD, and 4WD vehicles
• Approximately 20% increase in braking capability vs. stock/OEM systems
• Intelligent wheel slip control algorithms tuned per-vehicle
• Bosch Motorsport MM5.10 yaw/acceleration sensor included
• Dual 260 bar brake pressure sensors
• TTL wheel speed outputs (FL / FR / RL / RR) for logging and data acquisition
• Configurable via free Bosch RaceABS software

Technical Specifications

Kit Contents

RaceABS and Configuration

The Bosch Motorsport ABS M5 Clubsport is configured using Bosch's complimentary RaceABS calibration software. Vehicle-specific settings are quickly programmed through the software using a Bosch MSA-Box II USB interface (sold separately), allowing the system to be tailored to your chassis and braking package.

Typical configuration includes:

• Vehicle weight, wheelbase, and track width
• Individual wheel loads and tire rolling circumference
• Wheel speed sensor tooth count (increment count)
• Additional vehicle-specific ABS parameters

Which Wheel Speed Sensor / CAN Bus Speed Do I Need?

Not sure if your vehicle requires a DF11s (standard), DF11i (less common), or DF11v (rare) wheel speed sensor? We offer complimentary testing of your factory wheel speed sensor to identify the correct sensor type and matching CAN bus speed before your Bosch ABS M5 ships. Simply send us your sensor and we will test it for you, we only ask that you cover shipping to and from our facility. If it's not a direct plug and play option, we will help source an solution!

12-Position Function Switch

The included 12-position rotary switch allows the driver to instantly select the Bosch Motorsport ABS calibration best suited to changing track conditions without connecting a laptop.

• Dry / High-Grip: Minimal ABS intervention for maximum braking performance.
• Intermediate Grip: Balanced intervention for mixed conditions.
• Wet / Low Grip: Increased wheel slip allowance for rain, gravel, or low-traction surfaces.

Each switch position corresponds to a Bosch Motorsport pre-calibrated ABS map, allowing rapid adjustments at the track without modifying the underlying system calibration.

NOTE: All ABS Kits are shipped with insurance included in the freight cost.

Downloads

• Datasheet
• Operation Guide (ABS M5 Manual)
• CAD Drawing DXF (Components)
• Release Notes (RaceABS 2.0.1.19)
• Vehicle Datasheet
• DBC File (V15)
• Technical Service Note (Diagnostic Translation File)
• Cockpit Labels
• RaceABS M5 Software Tool 2.0.1.19
